150-194 – 0-30 OIL SYMBOL GAUGE PRESS BOOST MECH 1 / Vision Chrome 30 PSI Mechanical Boost Gauge 12V , VDO

150-194 - 0-30 OIL SYMBOL GAUGE PRESS BOOST MECH 1 / Vision Chrome 30 PSI Mechanical Boost Gauge 12V , VDO

VDO Part No.: 150 194

Diameter: 2 1/16 in

Diameter (Metric): 52mm

Dial Scale: Single

Input Type: Mechanical

Connection: 1/8-27 NPT

Mounting Hardware: U-Bracket

Voltage: 12V

Bezel: Black, Rectangular Version

Lens: Nonreflective

Deflector: Black

Dial: Backlighting

Dialgraphics: Black Background with White Characters

Pointer: Translucent Backlighting, Red

Housing: Steel, Zinc-Plated and Chromatized

Mounting: Bracket, Steel, Zinc-Plated and Chromatized

Illumination: Clear

Variable: Green or Red Colour Cap

Connections: Blade Terminals 6.3 x 0.8mm

Fitting: M12 x 1.5

TECHNICAL DATA:

Operating Temperature: -30°C to +85°C

Protection: IP64 DIN 40050 from the front

Nominal Position: NL 0 to NL 90, DIN 16257

Vibration Resistance: 1g eff. max., 25Hz to 2000Hz duration 8h, f: 1 octave/min

Indication Accuracy: ±4% of the full range for the last 2/3 of the scale

Light Bulb: 12V 2W or 24V 2W (option)
